GDS-GDH-GDM GUIDING UNITS


Guiding Units for pneumatic cylinders warrant an alignment guide and an antitorsion effect of the pneumatic component. The Guiding Units can be combined with cylinders and microcylinders ISO 6431 and ISO 6432. They are manufactured in three versions:
  • GDS: intended for limited loads and speeds, with aluminium alloy “U” body, sliding by means of sintered bronze, self lubricating rod guide brasses;
  • GDH: intended for high loads, with aluminium alloy “H” body, sliding by means of sintered bronze, selflubricating rod guide brasses;
  • GDM: intended for high speeds, with aluminium alloy “H” body, sliding by means of ball bearings.
