SANDWICH PRESSURE REGULATOR


The main function of sandwich pressure regulator is that of easing and simplifying the operation of these systems, thus avoiding complex wiring and expensive installation costs. The regulator installed between the sub-base and the valve makes it possible to adjust the pressure in four different configurations with various ISO 5599/1 sizes: 1 - 2 - 3.

TECHNICAL DATA:

Fluid: filtered, lubricated or not compressed air

Fixing: for sub-base ISO 5599/1

Inlet Pressure: Max 10 bar (144 Psi) (1 MPa)

Temperature Range: - min –10 °C - max +50 °C

Nominal Flow rate: Tg.1: 600 Nl/min - Tg.2: 1400 Nl/min - Tg.3: 1900 Nl/min

Knob: Lockable safety knob
